Trionic Platform Box

Product Highlights

The Platform Box is an integrated and compact solution for small Scissors and Mast lifts.

With its compact design, it provides four to six momentary switches for user specific functions and six indicator LEDs, as well as an optional Auxiliary connector for additional sensors or switches.

  • It has a three digit display showing battery charge status and fault codes to the operator
  • Pre-wired for easy installation
  • CANbus enabled
  • Customizable

General features

  • Analog inputs and switch inputs for joystick
  • Up to 6 momentary switches
  • Three digit display
  • Up to 6 LED indicators
  • CANbus interface to main valve/motor control module minimizes cable wiring/size
  • Integrated Buzzer and optional USB Charger

Technical Data

Power Supply12/24V 8.5 to 33 Vdc
AUX. Digital Inputs21.25kΩ imp.
 AUX. Analog Inputs20-5 V
Working Temperature

-40 to 50°C


1 Kg without cable

Overall Dimensions

10.9 x 5 x 9.3”

275 x 125 x 234 mm
